Call for Price
| System | ||
| Main Processor | Industrial-grade embedded processor | |
| Operating System | Embedded Linux | |
| Audio and Video | ||
| IP Camera Input | 64-channel IP camera input | |
| Two-Way Talk | 1-channel RCA, supports two-way audio using audio input and output | |
| Display | ||
| Interface | HDMI and VGA (independent output; simultaneous output supported by default) | |
| Resolution | HDMI: 4K (3840×2160) @30Hz, 1920×1080 @60/50Hz, 1600×1200, 1280×1024, 1280×720, 1024×768 VGA: 1920×1080 @60/50Hz, 1600×1200, 1280×1024, 1280×720, 1024×768 |
|
| Decoding Capacity | Ultra265/H.265: 2×16MP@30fps, 2×12MP@30fps, 4×4K@30fps, 6×5MP@30fps, 8×4MP@30fps, 10×3MP@30fps, 16×1080P@30fps, 32×960P@25fps, 36×720P@30fps, 64×D1 H.264: 2×16MP@30fps, 2×12MP@30fps, 2×4K@30fps, 4×5MP@30fps, 6×4MP@30fps, 8×3MP@30fps, 14×1080P@30fps, 28×960P@25fps, 30×720P@30fps, 64×D1 |
|
| Multi-Screen Display | Simultaneous output: VGA & HDMI 1/4/6/8/9/16/25/36/64 Independent output: VGA & HDMI 1/4/6/8/9/16/25/32 |
|
| OSD | Channel name, date, time, recording status, alarm status | |
| Recording | ||
| Compression | Ultra265 / H.265 / H.264 | |
| Resolution | 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1, 2CIF, CIF | |
| Record Rate | Up to 30fps per channel depending on resolution | |
| Bit Rate | Adaptive bit rate control | |
| Record Mode | Manual, Schedule, Motion Detection, Alarm | |
| Record Interval | Configurable | |
| Others | N+1 hot spare supported, ANR technology supported, cloud upgrade supported | |
| Video Detection And Alarm | ||
| Trigger Event | Motion detection, smart event, alarm input, system exception | |
| Video Detection | Face detection, intrusion detection, cross-line detection, people counting, vehicle detection, object left/removed, defocus detection, scene change detection, auto tracking, audio detection | |
| Alarm Input | 16-channel | |
| Relay Output | 4-channel alarm output | |
| Playback And Backup | ||
| Sync Playback | 16-channel synchronous playback | |
| Search Mode | Time search, alarm search, motion search, smart search, face search, vehicle search | |
| Playback Function | Play, pause, fast forward, rewind, frame-by-frame | |
| Backup Mode | USB device, network backup | |
| Third Party Support | ||
| Third Party Support | ONVIF Profile S / G / T, RTSP, mainstream IP camera compatibility | |
| Network | ||
| Interface | RJ45 | |
| Ethernet Port | 2 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports | |
| Network Function | CP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, 802.1X | |
| Maximum User Access | 128 remote users | |
| Smart Phone | Supported via mobile application | |
| Interoperability | Multi-brand IP camera integration | |
| Storage | ||
| HDD Mode | Up to 16TB per HDD, RAID 1 and RAID 5 supported, redundant storage supported | |
| Internal HDD | 8 SATA interfaces | |
| Auxiliary Interface | ||
| USB | Front: 2 × USB 2.0, Rear: 1 × USB 3.0 | |
| RS485 | 1 × RS485 | |
| Power | ||
| Power Supply | AC 100–240V | |
| Power Consumption | ≤ 32W (without HDD) | |
| Component Environment | ||
| Operational Conditions | -10°C to +55°C, ≤ 90% RH (non-condensing) | |
| Storage Conditions | Standard indoor storage conditions | |
| Construction | ||
| Dimensions | 442 mm × 426 mm × 89 mm | |
| Net Weight | ≤ 5.5 kg (without HDD) | |
| Gross Weight | Approximately 6.5 kg (package dependent) | |
| Warranty | ||
| Manufacturing Warranty | 1-year | |
When a building has dozens of cameras, its recorder must handle video, storage and review reliably. The Uniview NVR508-64B connects up to 64 IP cameras and brings eight hard-drive bays, 4K HDMI output and network connections to a single 2U unit.
For buyers checking the Uniview NVR508-64B price in Bangladesh, this listing is Call for Price. Request a quotation with your camera count, resolution, retention period and storage requirements. Touch IT can confirm compatible drives, PoE switches and installation scope.
This 64-channel network video recorder suits a campus, factory, warehouse or office needing central IP camera footage. It accepts Ultra 265, H.265 and H.264 streams and supports ONVIF Profiles S, G and T and RTSP. Confirm each camera's firmware and event features during integration.
The NVR508-64B has 64 camera inputs, with a 320Mbps incoming and 160Mbps outgoing bandwidth budget. Check each camera's expected bitrate and allow for remote viewing and playback. Maximum recording resolution is 16MP; practical stream combinations depend on codec, frame rate and bandwidth.
HDMI displays 3840 × 2160 at 30Hz; VGA supports 1920 × 1080 at 60Hz. With Ultra 265 or H.265, Uniview lists four 4K streams or two 16MP streams at 30fps for decoding. The 64-camera input limit is separate. A 64-window layout can use suitable lower-resolution streams, while local synchronous playback supports 16 channels.
Eight SATA bays let you size retention around bitrate and recording schedule. Uniview's current series sheet lists up to 24TB per compatible disk, subject to drive size and temperature conditions; confirm drives and firmware before purchase. RAID 1/5, disk groups and redundant storage support resilience. ANR and N+1 hot spare require compatible equipment and configuration.
The recorder can receive compatible camera-side events such as face or vehicle detection, intrusion, cross-line rules and people counting. Search tools narrow review by event or object type. Availability depends on camera support and settings. Explore a complete CCTV surveillance system when specifying cameras and recording together.
Two Gigabit RJ-45 ports support network planning. The chassis provides two front USB 2.0 ports, one rear USB 3.0 port, RS-485, 16 alarm inputs and four outputs. An RCA audio input/output pair supports one-channel two-way audio. The recorder uses AC 100–240V; cameras need suitable power equipment.
| Brand / model | Uniview NVR508-64B, 2U network video recorder |
|---|---|
| IP camera input | 64 channels; recording up to 16MP |
| Video formats | Ultra 265, H.265 and H.264 |
| Bandwidth | 320Mbps incoming; 160Mbps outgoing |
| Display outputs | 1 × HDMI up to 4K/30Hz; 1 × VGA up to 1080p/60Hz |
| Decoding examples | Ultra 265/H.265: 4 × 4K@30fps or 2 × 16MP@30fps |
| Local playback | 16-channel synchronous playback |
| Disk interfaces | 8 × SATA; current series documentation lists up to 24TB per qualified HDD under stated conditions |
| Storage features | Disk groups, redundant storage, RAID 1/5, ANR and N+1 hot spare |
| Network and USB | 2 × Gigabit RJ-45; 2 × front USB 2.0; 1 × rear USB 3.0 |
| Other interfaces | 16 alarm inputs, 4 alarm outputs, RS-485, RCA audio input/output |
| Power / dimensions | AC 100–240V; 442 × 426 × 89mm |
Storage check: Uniview documents give different per-drive limits over time. The current 24TB figure has drive and temperature conditions. Confirm qualified HDDs, firmware and usable RAID capacity when calculating retention.
| Uniview model | Camera / disk capacity | Choosing factor |
|---|---|---|
| NVR508-64B | 64 IP channels / 8 SATA bays | Up to 16MP recording, one HDMI and one VGA, RAID 1/5. |
| NVR304-32S | 32 IP channels / 4 SATA bays | Smaller camera and storage requirement. |
| NVR508-64E-R-IQ | 64 IP channels / 8 HDD bays | Up to 32MP recording, two HDMI/two VGA outputs and hot-swap RAID options. |
Yes. It accepts up to 64 IP channels, subject to its total 320Mbps incoming bandwidth budget.
No. Uniview lists up to four 4K/30fps decodes with Ultra 265 or H.265.
It has eight SATA bays. Confirm compatible drive capacity and whether disks are included.
ONVIF Profiles S, G and T and RTSP support integration; test camera streams and event compatibility.
Yes. Uniview lists RAID 1 and RAID 5, along with disk-group and redundant-storage features.
No camera PoE ports are listed. Plan separate PoE switches or other suitable camera power.
Yes. Local synchronous playback supports up to 16 channels, depending on the selected streams.
Touch IT can help size storage, select compatible Uniview products and plan camera power, networking and installation in Bangladesh. Confirm the supplied hardware revision, drives and warranty when ordering.
Request a current quotation from Touch IT for the NVR508-64B and your complete camera plan. Visit 312 (3rd Floor), Multiplan Center, 69–71 New Elephant Road, Dhaka-1205, or call 01711664030 to discuss stock, configuration and delivery.
