Dahua DHI-LPH86-MC480-U 86-Inch 4K EDLA AI Interactive Flat Panel with 48MP Camera

Dahua DHI-LPH86-MC480-U 86-Inch 4K EDLA AI Interactive Flat Panel with 48MP Camera

The Dahua DHI-LPH86-MC480-U is an advanced 86-inch 4K EDLA interactive flat panel for boardrooms, classrooms and hybrid workplaces. It combines Android 15, Google Play access, AI video conferencing, responsive digital whiteboarding and extensive connectivity in one professional display.

For organisations checking the Dahua DHI-LPH86-MC480-U price in Bangladesh, the current Touch IT price is ৳390,000. Its 48MP AI camera, 8-microphone array, 52W speakers, BYOM and 100W USB-C create an integrated collaboration solution.

Quick Highlights

• Display: 86-inch 4K UHD DLED panel with 400cd/m² typical brightness
• System: Android 15, RK3588 processor, 8GB RAM and 128GB storage
• Google Services: EDLA certified with access to Google Play Store
• AI Camera: 48MP Android photos, 8MP video, auto-framing and voice tracking
• Microphones: 8-mic array with voice pickup from up to 12 metres
• Touch: 32 points on Android and 50 points with Windows
• Audio: 52W 2.2-channel system with four built-in speakers
• Connectivity: Wi-Fi 6, Bluetooth 5.2, NFC and 100W USB-C

Product Overview

This business-class interactive flat panel replaces a projector, whiteboard, meeting camera and room speakers with one collaborative screen. Its 86-inch area keeps documents, dashboards, lessons and plans visible across larger rooms while presenters annotate directly.

Key Features and Benefits

Google EDLA and Android 15

Google EDLA certification provides a certified Google environment with Play Store access for compatible Android apps. The RK3588 processor combines four Cortex-A76 and four Cortex-A55 cores with Mali-G610 graphics, while 8GB RAM and 128GB storage support presentations, whiteboarding and workplace tools.

86-Inch 4K Screen with Zero Air Gap

The 3840 × 2160 DLED display offers 400cd/m² brightness, 1.07 billion colours, 90% NTSC coverage and 178-degree viewing. Zero Air Gap bonding improves visual alignment, while 3.2mm anti-glare tempered glass with at least 9H hardness protects the writing surface.

Fast 32/50-Point Interactive Writing

Infrared touch supports 32 points in Android and 50 with Windows. A response time of no more than 2ms and ±0.5mm accuracy across most of the screen help writing feel immediate. Users can write with a finger or magnetic stylus.

48MP AI Camera for Hybrid Meetings

The camera captures up to 48MP photos in Android and records 8MP or 4K video. Its 98-degree horizontal and 106-degree diagonal view suits wide seating. Auto-framing and voice tracking keep participants visible without constant adjustment.

8-Mic Array and 52W Room Audio

Eight microphones capture voices from up to 12 metres with gain control, echo cancellation and intelligent noise filtering. Four speakers use two 8W and two 18W drivers, delivering 52W 2.2-channel output for calls and presentations.

100W USB-C, BYOM and Flexible Connections

The front USB-C input supports 100W charging, data and network sharing for compatible laptops. BYOM brings a preferred meeting platform into the room workflow. Other interfaces include HDMI input/output, DisplayPort, USB-A, touch USB, audio, SPDIF, RS-232 and Gigabit LAN input/output.

Wireless Sharing, Wi-Fi 6 and NFC

Wi-Fi 6 provides dual-band network access, while hotspot mode enables local connections. Bluetooth 5.2 pairs compatible peripherals, NFC supports card interaction and wireless presentation simplifies content sharing.

Recommended Applications

• Executive boardrooms, conference rooms and hybrid meetings
• Universities, large classrooms and professional training centres
• Project planning, engineering reviews and design collaboration
• Government, healthcare and enterprise presentation facilities
• Google Workspace-oriented organisations requiring an EDLA display

Explore more technology for productive workplaces in the office equipment collection.

Technical Specifications

Model Verification Note

Current Dahua specifications list Android 15, 8GB RAM, 128GB storage and a 48MP-photo/8MP-video camera. Older regional pages describe Android 13, 16GB RAM and 256GB storage. Since specifications vary by country, confirm the hardware revision, EDLA status, wireless module, stand, OPS computer and warranty before ordering.

Why Choose the Dahua LPH86-MC480-U?

Choose this model when Google EDLA, Android 15, 100W USB-C, BYOM and integrated AI conferencing matter. It is a strong option for organisations seeking a future-ready 86-inch interactive whiteboard without building a meeting system from separate components.

Product Comparison

Browse more original Dahua products to compare interactive displays, compatible accessories and workplace solutions.

Frequently Asked Questions

What does EDLA certification provide?

It provides a Google-certified Android environment with Google Play Store access for compatible applications and services.

Does the panel have a built-in camera?

Yes. It supports 48MP photos in Android, 8MP video, auto-framing and voice tracking.

How many touch points does it support?

It supports 32 touch points in Android and up to 50 touch points with Windows.

Can USB-C charge a laptop?

Yes. The front USB-C port supplies up to 100W to a compatible USB Power Delivery device.

Does it work with Windows?

Yes. A compatible Windows computer can be connected, or an appropriate optional OPS module can be installed.

Is a mobile stand included?

The published packing list includes a wall-mount bracket. A compatible mobile stand is an optional accessory.
