| Camera System | ||
| Image Sensor | 1/3" progressive scan CMOS sensor, 4.0 megapixel | |
| Maximum Resolution | 4MP (up to 2592 × 1520) | |
| Scanning System | Progressive scanning | |
| Electronic Shutter Speed | Auto / Manual, 1 ~ 1/100000s | |
| Day / Night Mode | IR-cut filter with automatic switching (ICR) | |
| Minimum Illumination | Color: 0.03 Lux (F2.0, AGC ON); 0 Lux with IR | |
| Signal-to-Noise Ratio (S/N) | Greater than 55 dB | |
| Wide Dynamic Range (WDR) | True WDR up to 120 dB | |
| Digital Noise Reduction (2D/3D DNR) | Supported (2D & 3D DNR) | |
| Digital Defog | Digital Defog supported | |
| Pan / Tilt / Rotation | Pan: 0°–360° | Tilt: 0°–75° | Rotation: 0°–360° | |
| Infrared & Illumination | ||
| IR Type | Smart IR (Infrared LED) | |
| IR Distance | Up to 30 meters (98 feet) | |
| IR Control (Auto / Manual) | Auto / Manual selectable | |
| IR Wavelength | 850 nm | |
| Lens | ||
| Lens Type (Fixed / Varifocal / Motorized) | Fixed lens | |
| Focal Length & Field of View (FOV) | 2.8mm @ F2.0: Horizontal: 104.4° | Vertical: 67° | Diagonal: 135.7° 3.6mm @ F2.0: Horizontal: 86.4° | Vertical: 53.2° | Diagonal: 112.3° |
|
| Lens Mount | Board-mounted lens | |
| Iris Type | Fixed iris | |
| Aperture (F-number) | F2.0 | |
| DORI Distance | 2.8mm: Detect 63m | Observe 25.2m | Recognize 12.6m | Identify 6.3m 3.6mm: Detect 81m | Observe 32.4m | Recognize 16.2m | Identify 8.1m |
|
| Video & Image Processing | ||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |
| Smart Codec | Ultra 265 smart compression supported | |
| Main Stream / Sub Stream | Main stream, sub stream, and third stream supported | |
| Frame Rate | Main Stream: 4MP (2592×1520) up to 20fps 4MP (2560×1440) up to 25fps 3MP (2048×1520) up to 30fps Sub Stream: 2MP (1920×1080) up to 30fps Third Stream: D1 (720×576) up to 30fps |
|
| Supported Resolution | 4MP, 3MP, 2MP, D1 | |
| Bit Rate Control (CBR / VBR) | CBR and VBR supported (128 Kbps ~ 16 Mbps) | |
| Region of Interest (ROI) | Up to 8 configurable regions | |
| Scalable Video Coding (SVC) | ||
| On-Screen Display (OSD) | Up to 8 OSD areas | |
| Image Enhancement (BLC / HLC) | BLC and HLC supported | |
| White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 | |
| Gain Control | Automatic gain control (AGC) | |
| Privacy Masking | Up to 8 privacy mask areas | |
| Image Rotation / Flip | Normal, Vertical, Horizontal, 180°, 90° Clockwise, 90° Anti-clockwise | |
| Smart & AI Features | ||
| Motion Detection | Supported (up to 4 detection areas) | |
| Basic Event Detection | Motion detection, tampering alarm, scene change | |
| Advanced AI Analytics (Human / Vehicle / Face – Model Dependent) | Face detection, intrusion detection, line crossing, loitering, people counting | |
| Audio & I/O | ||
| Audio Interface | 1 audio input / 1 audio output | |
| Built-in Microphone | Not built-in (external audio input supported) | |
| Built-in Speaker | ||
| Audio Compression | G.711 | |
| Audio Sampling Rate | 8 kHz | |
| Two-Way Audio | Supported | |
| Alarm Events | 1 alarm input / 1 alarm output | |
| Reset Button | ||
| Network & Storage | ||
| Network Interface (RJ45) | 1 × RJ45 10M/100M Base-TX Ethernet | |
| Wireless Connectivity (Wi-Fi, If Available) | ||
| Network Protocols | IPv4, TCP, UDP, DHCP, RTP, RTSP, RTCP, HTTP, HTTPS, FTP, SMTP, DNS, DDNS, NTP, UPnP, SNMP, QoS, 802.1X | |
| ONVIF / Interoperability | ONVIF Profile S, G, T | |
| SDK & API Support | API supported | |
| Maximum User Access | ||
| Edge Storage (microSD) | Micro SD card supported, up to 256GB | |
| Network Storage (NAS / NVR) | ANR, NAS (NFS), NVR supported | |
| RS-485 | ||
| Software & Access | ||
| Web Browser Support | Plug-in free live view supported on modern browsers | |
| Management Software | EZStation | |
| Mobile App Support | EZView, EZLive | |
| Security Features | User authentication, IP address filtering, watermark, access control, ARP protection | |
| Power & Physical Specifications | ||
| Power Supply | DC 12V ±25% or PoE (IEEE 802.3af) | |
| Power Consumption | Maximum 5W | |
| Operating Temperature | -35°C to 60°C (-31°F to 140°F) | |
| Operating Humidity | ≤95% RH (non-condensing) | |
| Storage Temperature | -35°C to 60°C (-31°F to 140°F) | |
| Ingress Protection (IP Rating) | IP67 weatherproof | |
| Material | Metal + plastic housing | |
| Dimensions (L × W × H) | Φ108.5 × 81 mm (Φ4.28" × 3.2") | |
| Net Weight | 0.45 kg (0.99 lb) | |
| Installation Type | Ceiling or wall mount (eyeball dome) | |
| Compliance & Warranty | ||
| Certifications | CE (EN 60950-1), UL (UL60950-1), FCC Part 15 | |
| Manufacturer Warranty | 1-year warranty | |
The Uniview IPC324ER3-DVPF36 4MP WDR Vandal-resistant Fixed IR Eyeball Dome IP Camera is a reliable, high-performance surveillance solution designed for both indoor and outdoor security needs. Built with advanced imaging technology, strong night vision, and a rugged vandal-resistant body, this IP camera is ideal for offices, shops, warehouses, apartments, and commercial premises. Available at Touch IT , it delivers clear monitoring, durability, and smart features you can trust.
Equipped with a powerful 4MP resolution and up to 120 dB Wide Dynamic Range (WDR), this Uniview dome IP camera captures sharp, balanced images even in challenging lighting conditions. Whether it’s bright sunlight or deep shadows, WDR ensures important details are never lost, making it perfect for entrances, corridors, and high-contrast environments.
The camera supports full day/night functionality and features Smart IR technology for enhanced night-time visibility. With an IR distance of up to 30 meters (98 ft), it automatically adjusts infrared intensity to prevent overexposure, delivering clear and detailed images even in complete darkness.
To optimize storage and bandwidth, the camera supports Ultra 265, H.265, H.264, and MJPEG video compression formats. Built-in smart algorithms enhance detection efficiency, while ROI (Region of Interest) allows you to prioritize critical areas for higher video quality. The customized OSD feature offers flexible on-screen display settings to suit your monitoring needs.
The Uniview IPC324ER3-DVPF36 is designed for seamless integration with modern surveillance systems. It supports stable network connectivity and is fully ONVIF conformant, ensuring compatibility with a wide range of NVRs and third-party security platforms. This makes installation and system expansion easy and cost-effective.
Built to withstand tough environments, this eyeball dome camera comes with IK10 vandal resistance and IP67 ingress protection. It performs reliably in harsh weather conditions, operating within a wide temperature range of -35°C to 60°C. The wide input voltage tolerance of ±25% ensures stable operation even in areas with fluctuating power supply.
When you choose Touch IT, you get genuine Uniview products, expert support, and dependable after-sales service. The Uniview IPC324ER3-DVPF36 4MP WDR Vandal-resistant Fixed IR Eyeball Dome IP Camera is a smart investment for anyone seeking durable construction, intelligent security features, and professional-grade video surveillance.
Upgrade your security system today with Touch IT – where advanced technology meets trusted protection.
The latest price of Uniview IPC324ER3-DVPF36 Dome IP Camera in Bangladesh is 9,000৳. You can buy the Uniview IPC324ER3-DVPF36 Dome IP Camera at best price from our website or visit any of our showrooms.
